Product Features
◎ Sepa paint also called overspray filter, organ type filter paper which is the same as Andrea filter
◎ It is a new environmental protection product which is made of two pleated and perforated cardboard walls glued in their
edges. Sepa paint maintains the air clean without dirty air and water by eliminate paints, oil, glass raw materials,epoxy resin, tar, Teflon, plastic and other needless material effectively.
◎ Sepa paint can force the load flow change the direction many timesso that the particles which heavier than the air will be absorbed and the air will keeping moving forward. Particulars holding can reach 19Kg/m²
◎ Special size and thickness are available upon request
Application areas of Sepa paint
Ventilation andcooling, Civil applications, Humidity regulation, Industrial equipment, Poultry and livestock industry, Greenhouse and horticulture industry, Industrial cooling.
Technology Parameters
| Type | Dimensions W*H*T (cm) |
Pleat distance (mm) |
Air velocity (m/s) |
the resistance under appropriate wind velocity (m/s:Pa) |
Final pressure (Pa) |
Dust holding capqcity (kg/m²) |
Filter efficiency (%) |
Filter efficiency (%) |
Size of packing |
| SEPA PAINT-A | 1500*80*6 | 5 | 0.25-1.0 | 0.5/13 0.75/30 1/56 | 250 | 18 | 85-98 | White paperkraft fiher paper |
82*66*7 |
| SEPA PAINT-AA | 1000*90*6 | 5 | 0.25-1.0 | 0.5/13 0.75/30 1/56 | 250 | 18 | 85-98 | 92*62*7 | |
| SEPA PAINT-AAA | 1000*100*6 | 5 | 0.25-1.0 | 0.5/13 0.75/30 1/56 | 250 | 18 | 85-98 | 102*62*7 |
Bulk filter media for molecular gas pollution control, including activated carbon, enhanced performance impregnated activated carbon, potassium permanganate impregnated activated alumina and various mixed filter materials.
Learn More
Adding glue and strengthen hardness treatment, enhanced dust holding capacity, structure, and it's anti-extrusion, can be used many times after vacuuming or cleaning
Learn More
Various specifications are available for you to choose from Easy to identify front and back side
Learn More
Large specific surface area, well-developed cellular structure, high coal content, good air permeability and strong adsorption ability and can eliminate the dust.
Learn More
4 sizes to choose, can hold 25mm (1 inch), 50mm (2 inch), 75mm (3 inch) or 100mm (4 inch) thick filters. Special styles and filter frames can be customized Stainless steel material, strong and durable
