Disposable filters help prevent the potential spread of contaminants during filter handling and replacement.
They do not require regular cleaning or extensive maintenance, there is a reduced need for labor and associated costs.
Item NO. :
K59Optional Thickness :
120 / 150 / 220mmSeparator :
Hot melt beadGasket :
Pu endless gasket / EVA / EPDMSealant :
Pu two-component polyurethane glueFrame :
Aluminum / GI / SUSMedia :
Micro glass fiberEfficiency :
H13 / H14Max Temperature :
70℃Max Humidity :
100%
Product feature
◎ Good ventilation performance
◎ Special sealing technology, superior softness, non-deformation
◎ Light weight, easy installation and replacement
◎ Integrated design, can be with insulation and lifting lugs
◎ 100% factory inspection
Custom Design
Product Specification
Model NO. |
Actual Size HxWxD (mm) |
Air Flow (m³/h) |
Media Area Flow (m²) |
Velocity (m/s) |
---|---|---|---|---|
K59-001 | 610*610*120 | 1000 | 10.91 | 0.75 |
K59-002 | 570*1170*120 | 1800 | 19.08 | 0.75 |
K59-003 | 610*1220*120 | 2000 | 21.31 | 0.75 |
K59-004 | 610*610*150 | 1200 | 13.64 | 0.90 |
K59-005 | 570*1170*150 | 2150 | 23.85 | 0.90 |
K59-006 | 610*1220*150 | 2400 | 26.64 | 0.90 |
K59-007 | 610*610*220 | 1500 | 16.78 | 1.12 |
K59-008 | 570*1170*220 | 2700 | 29.36 | 1.12 |
K59-009 | 610*1220*220 | 3000 | 32.80 | 1.12 |
Application
Places with high requirement of cleanliness, such as surgery, lab, pharmacy, micro-electronic, fiber optic equipment and food processing factory, etc.
